🔌 Eaton Bussmann Cylindrical Fuses – Compact Protection for Industrial and Electrical Applications
Eaton Bussmann cylindrical fuses offer reliable overcurrent protection in compact form factors. Designed for low-voltage applications, they are available in standard sizes such as 10 x 38 mm, 14 x 51 mm, and 22 x 58 mm, with current ratings ranging from 0.25 A to 125 A. These fuses are ideal for control circuits, industrial machinery, photovoltaic systems, and general electrical distribution.
🔧 Technical Features
-
High breaking capacity: Safely interrupts high fault currents.
-
Compact and modular: Fits easily into tight spaces and modular DIN-rail systems.
-
Versatile applications: Suitable for industrial equipment, automation, HVAC, solar power, and more.
-
Durable construction: Made with robust materials for long-lasting performance.
-
Standards-compliant: Meets international standards such as IEC 60269 and BS88.
🔍 Product Overview – Example Part Numbers
| Part Number | Size (mm) | Current Rating | Voltage | Fuse Class | Indicator Pin |
|---|---|---|---|---|---|
| C10G6 | 10 x 38 | 6 A | 500 V | gG | No |
| C14M10S | 14 x 51 | 10 A | 500 V | aM | Yes |
| C22G32 | 22 x 58 | 32 A | 500 V | gG | No |
A wide range of additional fuse ratings and types are also available to meet specific protection needs.
🛠️ Matching Fuse Holders
Eaton Bussmann offers a full range of DIN-rail mountable fuse holders tailored to each fuse size:
-
CH10 for 10 x 38 mm (e.g. C10G6)
-
CH14 for 14 x 51 mm (e.g. C14M10S)
-
CH22 for 22 x 58 mm (e.g. C22G32)
These holders ensure safe and efficient installation, easy fuse replacement, and consistent contact performance.
✅ Benefits of Eaton Bussmann Cylindrical Fuses
-
Reliable protection for circuits, equipment, and personnel
-
Global availability and industry-standard compliance
-
Broad range of ratings for tailored protection
-
Simple integration into new or existing installations
-
Quality assurance from a trusted global manufacturer
🔍 Applications
-
Industrial control panels
-
Photovoltaic string protection
-
Semiconductor drive circuits (aM type)
-
General power distribution
-
Machine protection and motor circuits
Choose Eaton Bussmann cylindrical fuses for efficient, compact, and trusted protection in demanding low-voltage applications. Whether you're upgrading an industrial panel or designing a new system, these fuses provide performance you can count on.
